Affinity Plus Door Handle - 211mm Screw Centres - Inline Lever Pad Format

£0.00 GBP

- Affinity Plus Door Handle range suited with Affinity window handles, door hinges, knockers and letterplates
- Handles are non-handed allowing them to be used either left or right
- White and black powder coated are available in aluminium only
- Supplied with spring cassette and spindles for 70mm profile as standard - add suffix 44 to suit composite doors
- 12mm Backplate depth allows for standard size euro cylinders
Performance
- Endurance tested to 100,000 operations
- Pull tested to 100kg
Corrosion Resistance

All finishes meet requirements of BS EN 1670:2007 - grade 5 (480 hrs Salt Spray)
- Handle Lever/Backplate: Zinc Alloy BS1004A or Aluminium A360
- Spindle: Steel C1008, Zinc plated & yellow passivated
- Powder Coating: White, Black, Antique Black, Anthracite Grey, 60 microns minimum coating thickness
- PVD/Chrome Coating: Champagne Gold/Chrome/Flint/Satin Chrome & Brushed Nickel, multiple layer plating process

CODE PRE-FIX	FINISH	BUTTON OPTIONS (ADD ONE OPTION TO CODE)			HANDING (ADD ONE OPTION TO CODE)		SPINDLE (ADD ONE OPTION TO CODE)	NON-LOCK	ALUMINIUM
		BLACK	WHITE	GREEN	LEFT	RIGHT
WHAP	WH	BB	WB	GB	L	R	9/15/20/25/30/35/40/55/60	NL	A
WHAP	BL	BB	-	-	L	R	9/15/20/25/30/35/40/55/60	NL	A
WHAP	AB	BB	-	-	L	R	9/15/20/25/30/35/40/55/60	-	A
WHAP	TB	BB	-	-	L	R	9/40	-	A
WHAP	GR	BB	-	-	L	R	9/15/20/25/30/35/40/55/60	-	A
WHAP	CG	BB	-	-	L	R	9/15/20/25/30/35/40/55/60	-	-
WHAP	CH	BB	-	-	L	R	9/15/20/25/30/35/40/55/60	-	-
WHAP	SC	BB	-	GB	L	R	9/15/20/25/30/35/40/55/60	NL	-
WHAP	BN	BB	-	-	L	R	9/15/20/25/30/35/40/55/60	-	-
